16. Relay test
The current status of the output relay can be requested in the Relay test menu.
If the relay test is activated, all outputs are switched off at the same time. Following that, each output can be
switched on or off individually.
If you forget to switch off the relay test at the end of the test, it is ended automatically after 15 minutes.
16.1. Relay test menu
Parameter
Designation
Value
Min.
Max.
Comment
R
W
23-084
Activate
relay test
0
0
1
Activate relay test
0=OFF
1=ON
3
3
21-036
VA1 HW output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-037
VA2 HW output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-038
VA3 HW output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-039
VA1-FE1 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-040
VA2-FE1 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-041
VA3-FE1 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-043
VA1-FE2 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-044
VA2-FE2 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
21-045
VA3-FE2 HW
output
0
0
1
Status output / activation 0=OFF 1=ON
3
3
17. Sensors
In the Sensors menu, it is possible to set the corresponding input/sensor type for each input.
17.1. Sensors menu
Parameter
Designation
Value
Min.
Max.
Comment
R
W
33-000
VE1 sensor type
0=KTY
0=KTY
1=PTC
2=PT1000
4
4
33-001
VE2 sensor type
0=KTY
0=KTY
1=PTC
2=PT1000
4
4
33-002
VE3 sensor/input type
0=KTY
0=KTY
1=PTC
2=PT1000
4=IMP (passive = only contact)
4
4
33-003
VE10V input type
5
0=….
1= …..
4
4
33-004
FVT-T input type
0=KTY
0=KTY
1=PTC
2=PT1000
4
4
33-005
FVT-F input type
5
3=IMP (active = flow rate sensor)
4=IMP (passive = only contact)
4
4
33-006
VE1-FE1, config. input
0
"0=KTY
1=PTC
2=PT1000
4
4
