3. Technical data
Designation/type
TopTronic E
GLT module
TopTronic E
Module expansion
Abbreviation TTE-GLT TTE-FE
Power supply max 230 V AC +6 - 10% 230 V AC +6 - 10%
Frequency 50 – 60 Hz 50 – 60 Hz
Max. power consumption incl.
bus supply, module expansions
18.9 W 1.8 W
Max. power consumption
7.8 W 1.8 W
Fuse 10 A slow-blow
none - protection
via controller module
Outputs (high-voltage)
Fully electronic relays 0 0
Electromechanical relays 3 3
Outputs (extra-low voltage)
Signal output PWM or 0-10V 1 1
Switching capacity
Electromechanical relays 2 (2) A 2 (2) A
Inputs (high-voltage)
Optocoupler input 1 1
Inputs (extra-low voltage)
Input 0-10V 1 1
Inputs sensors 2 2
Inputs flow rate sensor 1 1
Pulse input 1 (can be switched over to sensor) 1 (can be switched over to sensor)
Voltage measuring circuit 15 V, with protective isolation 2.9 kV 15 V, with protective isolation 2.9 kV
Expansion (module expansion)
Max. number 2
-
Casing
Assembly Top hat rail mounting (35x15) Top hat rail mounting (35x15)
Dimensions W/H/D in mm
incl. plug
150x100x75 150x100x75
Ambient temperature 0 … 50°C 0 … 50°C
Storage temperature - 20 ... 60°C - 20 ... 60°C
Bus system (Hoval CAN bus)
Capacity
max. 4 control modules /
3 control modules + 1 gateway
-
Bus supply yes none
Bus line 4-wire bus -
Bus length twisted, shielded, max. 100 m -
Line cross-section min 0.5 mm² -
Other bus interfaces
internal unit bus (master) internal unit bus (slave)
-
-
Miscellaneous
Spring reserve 10 years, battery buffered -
Type of protection IP 20 IP 20
Protection class II – EN 60730 II – EN 60730
Plug types Rast5 (coloured, coded) Rast5 (coloured, coded)
