PL1200 Thermal Transfer Printer
Operations
4.2 About Changing Media Reels
Before label media reels can be changed and for ease of changing thermal transfer print and
label tape, always remove the PL1200 labeling unit from the docking station. Once removed, lay
the labeling unit on its back. This makes it easier to handle the label media reels. Before the
reels can be removed, the drive arm ‘lock knob’ need to be set in the open position as seen in
diagram 4.2a.
Diagram 4.2a
Drive arm
'lock knob'
