The Pilot is easily height and tilt adjustable via the podium
control panel (located on the upper-right corner of the
podium surface). The podium can go from a minimum
height of 28in to a maximum height of 40in. The surface
can tilt from 0º (flat) to 30º (tilted).
The Podium’s adjustability is compliant with the ADA
wheelchair accessibility standards.
For added convenience, the Pilot includes an attachable side
tray for additional desk real-estate. The tray is sturdy enough to
support a laptop, and can be positioned right next to the HDMI
inputs for simple interfacing.
Before installation, make sure the Pilot is in flat mode. To install,
simply guide the trey into the two seating holes on either side of
the Pilot, and slide to the right until it locks in place. Next, insert
the support bar into the two support bar seating holes, and
fasten it with the included support bar key and nut.
