Single-phase Microinverter User Manual
5. About Installation
5.1 Accessories
Object Description
A AC Bus Cable, 12/10 AWG Cable
B DC Extension Cable, 1 m
C M8 × 25 Screws
D AC Connector Unlocking Tool
E Bus Connector Unlocking Tool
F AC Sub Cap
G AC Bus End Cap, IP67
*Note: All accessories listed above are not included in the package, and need to be purchased separately. Please
contact our sales representative for pricing information. (M8 screws need to be prepared by installer-self.)
5.2 Installation Precautions
Please install the microinverter and all DC
connections under the PV module to avoid
direct sunlight, rain exposure, snow pile-up,
UV, etc. Allow a minimum of 2 cm of space
around the microinverter enclosure to
ensure ventilation and heat dissipation.
*Note: For some countries, the DTU will
be required to meet local grid regulations
(e.g.G98/99 for UK).
