Single-phase Microinverter User Manual
3. About Product
3.1 About 4-in-1 Unit
“Daisy-Chain 4-in-1 Unit Microinverter” with ultra-wide DC input operating voltage range (16 V–60 V) and low
start-up voltage (22 V only).
The Hoymiles 4-in-1 Unit Microinverter HM-1000T/HM-1200T/HM-1500T is a reliable solution for PV systems
with an uneven number of panels, and offers high CEC weighted efficiency – 96.50% (peak efficiency 96.70%)
in 2015.
3.2 Highlights
• Maximum output power up to 1000 W/1200 W/1500 W. Adapted to 60-cell & 72-cell PV panels.
• Peak eciency 96.70%. CEC weighted eciency 96.50%.
• Static MPPT eciency 99.80%. Dynamic MPPT eciency 99.76% in overcast weather.
• Power factor (adjustable) 0.8 leading…0.8 lagging.
• External antenna for stronger communication with DTU.
• High reliability: NEMA 6 (IP67) enclosure. 6000 V surge protection.
3.3 Terminals Introduction
Object Description
A AC Connector
B DC Connector
C AC Connectors
3.4 Dimension (mm)
Unit: mm
