Single-phase Microinverter HMS-1600/1800/2000-4T-NA
9. Grid Support Details
The HMS-1600-4T-NA/ HMS-1800-4T-NA/ HMS-2000-4T-NA Microinverter is a grid support interactive
inverter, which is also known as a Grid Support Utility Interactive Inverter. And these microinverters also
comply with California Rule 21. The Grid Support functions are controlled on Hoymiles Monitoring Platform
and the DTU is required in this PV system.
Manufacturer’s Stated Accuracy
SA9: Low/High Voltage Ride Through (L/H VRT) and Must Trip Settings
Only an authorized installer is allowed to make grid prole adjustments according to the
requirements of local utility.
Using Fixed Power Factor and Volt/Var at the same time is not supported.
Measure Default Tolerance of Measurement
Volt +/-1%
Watt +/-5%
VAr +/-6%
Power factor +/-0.05
Hz +/- 0.1 Hz
Region
Voltage at
PCC
(% Nominal
Voltage)
Ride-Through
Until
Operating
Mode
Maximum
Trip Time (s)
Range of
Adjustable
Maximum
Trip Time (s)
High Voltage 2
(HV2)
V
≥
120 N/A N/A 0.16 0.16
High Voltage 1
(HV1)
110 < V < 120 12 sec.
Momentary
Cessation
13 1-13
Near Nominal
(NN)
88
≤
V
≤
110 Indenite
Continuous
Operation
N/A N/A
Low Voltage 1
(LV1)
70
≤
V < 88 20 sec.
Mandatory
Operation
21 21
Low Voltage 2
(LV2)
50
≤
V < 70 10 sec.
Mandatory
Operation
11 11-21
Low Voltage 3
(LV3)
V < 50 1 sec.
Momentary
Cessation
1.5 1.5-2
Grid Support Details

Hoymiles HMS-2000-4T Specifications

General

Output current	8.7 A
Charging voltage	230 - 275 V
Operating temperature (T-T)	-40 - 65 °C

Weight and Dimensions

Depth	34.6 mm
Width	331 mm
Height	218 mm
Weight	4700 g
