Bottom
Component Description
(1) Battery lock Locks the battery in the battery bay.
(2) Battery bay Holds the battery.
(3) Battery release
latch
Releases the battery.
(4) Speakers (2) Produce sound.
(5) Vent Enables airow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal components and
prevent overheating. It is normal for the internal fan to cycle on and o during
routine operation.
Bottom 15
