HP 14-BS0 Series - Page 26

Item Component Spare part
number
(1) Display assembly
NOTE: For display assembly spare part information, see Display assembly subcomponents
on page 21.
not spared
(2) Top cover/keyboard
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 77.
Jet black 925307-xxx
Snow white 925308-xxx
Smoke gray 925309-xxx
(3) TouchPad button board 925365-001
(4) Speakers (includes left and right speakers and cable) 925376-001
(5) Power connector cable 938292-001
(6) USB board
For use in models with Intel Pentium or Celeron processors 925363-001
For use in models with Intel Core processors 925364-001
(7) Power button board 925366-001
(8) Hard drive bracket 925354-001
(9) Hard drive, 2.5 inch (does not include bracket, connector board, or cable)
1-TB, 5400-rpm 778192-005
500-GB, 5400-rpm 778186-005
eMMC module, 128 GB (not illustrated) 942826-001
(10) Solid-state drive, M.2
NOTE: Mylar for use with solid-state drives is available using spare part number 930980-001.
512 GB 763008-015
256 GB 865902-011
128 GB 827560-040
(11) Solid-state drive bracket 925355-001
(12) System board (includes replacement thermal materials)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in models with discrete graphics memory
●
Intel Core i7-7500U processor and 4 GB of discrete graphics memory 925428-xx1
●
Intel Core i7-7500U processor and 2 GB of discrete graphics memory 925429-xx1
●
Intel Core i5-8250U processor and 2 GB of discrete graphics memory 941656-xx1
18 Chapter 3 Illustrated parts catalog
