Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display
NOTE: Displays are not spared as whole units. Display subcomponent spare parts are
available.
For spare part information, see Display assembly subcomponents on page 21.
Not spared
(2) Top cover/keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 75.
Keyboard, no backlight, jet black L22751-xx1
Keyboard, no backlight, snow white L22752-xx1
Keyboard, no backlight, ash silver L22750-xx1
Keyboard, no backlight, jet black, mesh knit pattern L48409-xx1
Keyboard, no backlight, snow white, mesh knit pattern L48410-xx1
Keyboard, backlit, ash silver (available only with -001 United States keyboards) L22749-001
Keyboard, no backlight, tranquil pink (available only with -001 United States keyboards) L26985-001
Keyboard, no backlight, iridescent pale rose gold (available only with -001 United States
keyboards)
L26986-001
Keyboard, no backlight, iridescent ceramic white (available only with -001 United States
keyboards)
L26987-001
Keyboard, backlit, tranquil pink (available only with -001 United States keyboards) L28089-001
Keyboard, backlit, iridescent pale rose gold (available only with -001 United States
keyboards)
L28090-001
Keyboard, backlit, iridescent ceramic white (available only with -001 United States
keyboards)
L28091-001
(3) TouchPad module L28085-001
(4) TouchPad button board L22539-001
(5) Speakers (includes cable) L22580-001
(6) Power connector cable (DC-in) L22528-001
(7) System board hook L22748-001
(8) System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with discrete graphics memory:
● AMD Ryzen 3-3200U processor L46462-xx1
● AMD Ryzen 3-2200U processor L22725-xx1
● AMD A9-9425 processor L22726-xx1
Computer major components 17
