TouchPad module
Table 6-12 TouchPad module and cable descriptions and part numbers
Description Spare part number
TouchPad module L28085-001
TouchPad module cable L22525-001
Before removing the TouchPad module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the optical drive (see Optical drive on page 33).
3. Remove the bottom cover (see Bottom cover on page 37).
4. Remove the battery (see Battery on page 40).
To remove the TouchPad module:
1. Disconnect the cable from the ZIF connector on the TouchPad (1).
2. Lift the tape from the TouchPad (2).
3. Lift the tape up to gain access to the TouchPad (3).
4. Starting in the corner, use a plastic, non-marking tool to pry up the TouchPad module to disengage the
adhesive that secures it to the top cover (1)
Component replacement procedures 53

HP 17 Series Specifications

General

Display Size	17.3 inches
Operating System	Windows 10 or Windows 11
Battery Life	Varies by model and usage
Battery	3-cell or 4-cell Li-ion
Ports	USB Type-A, USB Type-C, HDMI, SD card reader, headphone/microphone combo (varies by model)
Wireless	Wi-Fi 802.11ac or 802.11ax, Bluetooth
