Optical drive board
Table 6-10 Optical drive board and cable descriptions and part numbers
Description Spare part number
Optical drive board L22540-001
Optical drive board cable L22524-001
Before removing the optical drive board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the optical drive (see Optical drive on page 33).
3. Remove the bottom cover (see Bottom cover on page 37).
4. Remove the battery (see Battery on page 40).
Remove the optical drive board:
1. Disconnect the cable from the ZIF connector on the optical drive board (1).
2. Remove the two Phillips M2.0 × 3.0 screws (2), and then remove the board from the computer (3).
Reverse this procedure to replace the optical drive board.
Component replacement procedures 51

HP 17 Series Specifications

General

Display Size	17.3 inches
Operating System	Windows 10 or Windows 11
Battery Life	Varies by model and usage
Battery	3-cell or 4-cell Li-ion
Ports	USB Type-A, USB Type-C, HDMI, SD card reader, headphone/microphone combo (varies by model)
Wireless	Wi-Fi 802.11ac or 802.11ax, Bluetooth
