HP 1810-8G Installation And Getting Started Guide

2-6
Installing the Switch
Installation Procedure
Note The 1810-24 and 1810-24G Switches do not have a power switch. They are
powered on when the power cord is connected to the switch and to a power
source. For safety, the power outlet should be located near the switch
installation.
Connect the power cord to the switch
and an AC power outlet
1810-8 and 1810-8G Switch
1810-24 and 1810-24G Switch
Connect inline AC/DC power adapter to
the switch and an AC power outlet
Connect wall plug-in AC/DC power adapter
to the switch and an AC power outlet

HP 1810-8G Specifications

General

Switching Capacity	16 Gbps
Throughput	11.9 Mpps
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
PoE	No
Weight	2.2 lb (1 kg)
Ports	8 x 10/100/1000
Form Factor	Desktop, Rack-mountable
Management	Web-based
Power Supply	External
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
