1-2
Switch Overview
Switch Hardware Features
Switch Hardware Features
HP 1810-8 Switch (J9800A)
Power and
Fault LEDs
Link/Act and Speed LEDs
10/100BASE-TX RJ-45 ports
1
10/100/1000BASE-T RJ-45 port
1
Locator LED
Reset and Clear buttons
HP 1810-24 Switch (J9801A)
Power, Fault, and
Locator LEDs
Link/Act and Speed LEDs
10/100BASE-TX RJ-45 ports
1
10/100/1000BASE-T
RJ-45 ports
1
Reset and Clear buttons
SFP slots
HP 1810-8G Switch (J9802A)
Link/Act and Speed LEDs
10/100/1000BASE-T RJ-45 ports
1
Power and
Fault LEDs
Locator LED
Reset and Clear buttons
PoE PD port
1
All RJ-45 ports have the Auto-MDIX feature.
