Item Component Spare part
number
(1) Display
NOTE: Displays are not spared as whole units. Display subcomponent spare parts are available. For
spare part information, see Display assembly subcomponents on page 19.
Not spared
(2) Top cover/keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 58.
L44060-xx1
(3) TouchPad module L22586-001
(4) TouchPad button board L23197-001
(5) TouchPad button board bracket L23193-001
(6) Power connector cable (DC-in) L23188-001
(7) System board (includes integrated processor)
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with 2 GB of discrete graphics memory:
●
Intel Core i7-8565U processor L38148-xx1
●
Intel Core i7-8550U processor L23228-xx1
●
Intel Core i5-8265U processor L38150-xx1
●
Intel Core i5-8250U processor L23227-xx1
●
Intel Core i3-7020U processor L23226-xx1
For use in models with UMA graphics memory:
●
Intel Core i5-8265U processor L38151-xx1
●
Intel Core i5-8250U processor L23232-xx1
●
Intel Core i3-7020U processor L23230-xx1
●
Intel Pentium N5000 processor L23236-xx1
●
Intel Celeron N4000 processor L23234-xx1
(8) USB/card reader/power button board L23196-001
(9) System board hook L23206-001
(10) Speakers (includes cable) L23221-001
(11) Fan L23189-001
Heat sink
(12) Heat sink for use in models with Intel Core processors and discrete graphics L23192-001
(13) Heat sink for use in models with Intel Core processors and integrated UMA graphics L23191-001
(15) Fan insert (for use in fanless models) L23198-001
Computer major components 17
