Solid-state drive
Description Spare part number
256 GB, PCIe, NVMe, value L44333-001
256 GB, SATA-3, TLC L23223-001
128 GB, SATA-3, TLC L23222-001
Optane memory module, 16 GB L42281-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery (see Battery on page 29).
Remove the solid-state drive:
▲
Remove the Phillips M2.0×3.0 screw (1), and then pull the solid-state drive module from the socket (2).
Reverse this procedure to install the solid-state drive.
Component replacement procedures 35
