HP 240 G7

System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Description Spare part number
System board for use in models with discrete graphics memory:
●
Intel Core i7-8565U processor L38148-xx1
●
Intel Core i7-8550U processor L23228-xx1
●
Intel Core i5-8265U processor L38150-xx1
Intel Core i5-8250U processor with 2 GB of discrete graphics memory L23227-xx1
Intel Core i3-7020U processor with 2 GB of discrete graphics memory L23226-xx1
System board for use in models with UMA graphics memory:
●
Intel Core i5-8265U processor L38151-xx1
●
Intel Core i5-8250U processor L23232-xx1
●
Intel Core i3-7020U processor L23230-xx1
●
Intel Pentium N5000 processor L23236-xx1
●
Intel Celeron N4000 processor L23234-xx1
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the following components:
a. Bottom cover (see Bottom cover on page 27)
b. Battery (see Battery on page 29)
c. Hard drive (see Hard drive on page 33)
d. Solid-state drive (see Solid-state drive on page 35)
e. WLAN module (see WLAN module on page 36)
f. Memory modules (see Memory on page 31)
g. Fan (see Fan on page 41)
Remove the system board:
IMPORTANT: Make special note of each screw size and location during removal and replacement
1. Disconnect the following cables from the system board:
(1): Hard drive cable
(2): Display cable
