Speakers
Description Spare part number
Speaker Kit L23221-001
Before removing the speakers, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 27).
5. Remove the battery (see Battery on page 29).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Lift the tape that secures the speaker cable to the system board (2), and then lift the speakers from the
computer (3).
Reverse this procedure to install the speakers.
Component replacement procedures 39
