Front panel components
Front panel components
1 USB SuperSpeed ports (2) 3 Hard drive activity light
2 Audio-out (headphone)/Audio-in (microphone) combo jack 4 Power button
Rear panel components
Rear panel components
1 Antenna cover 7 USB SuperSpeed ports (2)
2 Access panel thumbscrew 8 Serial port
3 Security cable slot 9 USB ports with optional keyboard power-on support (2)
4 Padlock loop 10 RJ-45 (network) jack
5 HDMI monitor port 11 Power connector
6 VGA monitor connector
2 Chapter 1 Product features
