HP 260 G3 User Manual

Speaker
A single speaker is located on the left side of the computer behind the front bezel.
To remove the speaker:
1. Prepare the computer for disassembly (Preparation for disassembly on page 14).
2. Remove the access panel (Access panel on page 15).
3. Disconnect the speaker cable from the system board connector (1).
4. From the front of the computer, remove the Phillips screw that secures the speaker to the chassis (2).
5. Remove the insulator and tape from the top and inside of the speaker (3).
6. Lift the speaker straight up and out of the bracket on the inside of the chassis (4).
To install the speaker, reverse the removal procedures.
Speaker 17

HP 260 G3 Specifications

General

Operating System	Windows 10 Pro
Processor	Intel Celeron, Pentium, or Core i3/i5/i7
RAM	Up to 16GB DDR4
Storage	500GB HDD
Graphics	Intel HD Graphics
Form Factor	Mini PC
Networking	10/100/1000 Gigabit Ethernet
Ports (Front)	2x USB 3.0, 1x headphone/microphone combo
Ports (Rear)	2x USB 2.0, 1x HDMI, 1x VGA, 1x RJ-45
Power Supply	65W external adapter
Dimensions	177 x 34 x 175 mm
Ports	1x HDMI, 1x VGA, 1x RJ-45
