Front bezel
NOTE: It is not necessary to remove the front bezel to access other components.
The front bezel is secured to the access panel with screws.
1. Prepare the computer for disassembly (Preparation for disassembly on page 14).
2. Remove the access panel (Access panel on page 15).
3. Position the access panel upside-down so you can access the inside of the bezel.
4. Remove the two Phillips screws (1) that secure the bezel to the access panel.
5. Simultaneously press the two top tabs (not the four bottom tabs) to disengage the bezel (2).
6. Rotate the top of the bezel downward away from the access panel(3), and then remove it (4).
To install the front bezel, reverse the removal procedure.
16 Chapter 4 Removal and replacement procedures
