6. Under I need help immediately, click System Recovery.
7. Select Yes, and then click Next. Your computer restarts.
8. When the computer restarts, you will see the Recovery Manager welcome screen again. Under I need
help immediately, click System Recovery. If you are prompted to back up your files, and you have not
done so, select Back up your files first (recommended), and then click Next. Otherwise, select Recover
without backing up your files, and then click Next.
9. System Recovery begins. After System Recovery is complete, click Finish to restart the computer.
10. When Windows has loaded, shut down the computer, reconnect all peripheral devices, and then turn the
computer back on.
System Recovery when Windows is not responding
CAUTION: System Recovery deletes all data and programs you created or installed.
If Windows is not responding, but the computer is working, follow these steps to perform a System Recovery.
1. Turn off the computer. If necessary, press and hold the power button until the computer turns off.
2. Disconnect all peripheral devices from the computer, except the monitor, keyboard, and mouse.
3. Press the power button to turn on the computer.
4. As soon as you see the HP logo screen, repeatedly press the F11 key on your keyboard until the
Windows is Loading Files… message appears on the screen.
5. At the HP Recovery Manager screen, follow the on-screen instructions to continue.
6. When Windows has loaded, shut down the computer, reconnect all peripheral devices, and then turn the
computer back on.
System Recovery using recovery media (select models only)
Use the steps provided in this section if you created recovery media using Creating recovery media using HP
Recovery Manager (select models only) on page 111. If you used HP Recovery Disc Creator to create a
Windows 7 operating system DVD and a Driver Recovery DVD, use the steps in
Using HP Recovery Disc
operating system discs (select models only) on page 116.
CAUTION: System Recovery deletes all data and programs you have created or installed. Back up any
important data to a CD or DVD or to a USB flash drive.
To perform a System Recovery using recovery media:
1. If you are using a set of DVDs, insert the first recovery disc into the DVD drive tray, and close the tray. If
you are using a recovery USB flash drive, insert it into a USB port.
2. Click the Start button, and then click Shut Down.
or
If the computer is not responding, press and hold the power button for approximately 5 seconds or until
the computer turns off.
3. Disconnect all peripheral devices from the computer except the monitor, keyboard, and mouse.
4. Press the power button to turn on the computer, and press Esc as the computer is powering on to
display the startup menu.
5. Use the arrow keys to select the boot menu, and press Enter. Use the arrow keys to select the location
where the recovery media is inserted (USB or DVD). Press Enter to boot from that device.
Backing up, restoring, and recovering in Windows 7 115

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 280 G1 and is the answer not in the manual?

HP 280 G1 Specifications

General IconGeneral
Tcase72 °C
Bus typeDMI
SteppingC0
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modelG3250
System bus rate5 GT/s
Processor familyIntel Pentium G
Processor seriesIntel Pentium G3000 series for Desktop
Processor socketLGA 1150 (Socket H3)
Processor codenameHaswell
Number of QPI links0
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)53 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1333 MHz
Memory bandwidth supported by processor (max)21.3 GB/s
Maximum internal memory supported by processor32 GB
Operating system installedWindows 7 Professional
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1600 MHz
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integrated-
Total storage capacity500 GB
Product typePC
Motherboard chipsetIntel® H81
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics
Maximum on-board graphics card memory1.7 GB
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.1
On-board graphics card dynamic frequency (max)1100 MHz
Number of displays supported (on-board graphics)3
Power supply180 W
Ethernet LAN data rates10, 1000, 100 Mbit/s
USB 2.0 ports quantity6
Scalability1S
Processor codeSR1K7
Processor ARK ID83538
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, SSE4.2
Thermal solution specificationPCG 2013C
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Weight and Dimensions IconWeight and Dimensions
Depth355 mm
Width165 mm
Height358.8 mm
Weight7050 g
