Power supply
Description
Power supply, 280W, 92% efficient
Power supply, 280W, 90% efficient
Power supply, 280W, 85% efficient (for use only in China)
Power supply, 280W, standard
1. Prepare the computer for disassembly (Preparation for disassembly on page 21).
2. Remove the access panel (
Access panel on page 22).
3. From the outside, rear of the computer, remove the four silver Torx screws that connect the power
supply to the chassis.
Power supply 47
