Removal and Replacement 7-13
Replacement:
1. Align the bay with the chassis.
2. Push the bay into the chassis until it fully seats into the system card.
3. Tighten the four captive mounting screws.
4. Replace the front bezel.
Upper Peripherals
Removal: Refer to Figure 7-11 and Figure 7-12
1. Remove the peripheral bay.
2. Remove the peripheral interconnect card (1) located on the back of the peripheral bay. Grasp the card
by the edges, lift up and pull away from the bay (it is mounted by keyed slots (2)).
3. Disconnect the device SCSI cable (3) and power cable (4).
NOTE
Make sure all device mounting screws are installed, the interconnect card is properly seated on the
mounting pegs, and that all cables are inside the peripheral bay sheet metal.
To Next Page
