15
Power board
The power board part number is PLPCHL351UQA2
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 9.
Remove the power board:
1) The HP 32s power board connector position is as follows:
2) Locate the part number location on the board.
Warning: After unplugging the
power supply, the capacitance
is still charged, do not touch
and discharge the capacitor.
To Next Page
