Connector repair
This procedure includes HDMI, D-sub connectors.
The connectors are on the main board(spare part number CBPCLC3HPQ1).
The connectors identifiers are as follows:
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 9
.
IMPORTANT:
• Repair Condition: Connector repair is only for out of warranty.
• Repairing must operate by professional repairers (Note) in repair center, not applicable for end user.
• Electrostatic protection is required when component replacement is required.
• The monitor meets ROHS, please use Lead-free solder wire for soldering.
• If Connector need to replace, must check specification and part number whether match the BOM and
location.
• If connector need to replace, please insert new parts carefully because the near pin may cause short
circuit by inappropriate operate.
• DO NOT allow any liquid on the board. Water and moisture may cause short-circuit to the electronic
components and lead to malfunctions.
• The fusion point of Lead-Free solder is requested. Repairing with conventional lead wire may cause
damage.
• Work quickly to avoid overheating the circuit board as soon as you confirm the steady soldering
condition.
• Keep the soldering iron tip clean and well tinned and when replacing parts.
• A close inspection of the circuit board revealed look in good condition.
