D-sub connector CN101
Repair the D-sub connector:
1. Use a soldering iron and a desoldering pump to remove as much solder as possible from the pin.
2. Lift the CN101 connector from the PCB.
3. Place the new component on the PCB. Be sure that it matches the PCB footprint.
4. Solder the new component.

HP 32s Specifications

General

Pixel pitch	0.363 x 0.363 mm
Screen shape	Flat
Display diagonal	31.5 \
Display technology	LED
Contrast ratio (dynamic)	6000000:1
Contrast ratio (typical)	1200:1
Display number of colors	-
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Depth	58.3 mm
Width	729.7 mm
Height	432.8 mm
Weight	7720 g
Tilt angle range	-5 - 13 °
Product color	Black
Country of origin	China
Market positioning	Home
AC input voltage	100 - 240 V
Power consumption (max)	39 W
Annual energy consumption	51 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	36 W
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Harmonized System (HS) code	85285210
Package weight	10830 g

Weight and Dimensions

Depth (with stand)	219.1 mm
Height (with stand)	497.8 mm
