6Go to the BURST PHAS command in the MOD MENU.
6:BURST PHAS
7 Move down a level and set the burst phase.
You can set the starting phase of the burst to any value between
-360 degrees and +360 degrees. With the
BURST PHAS command,
the phase adjustment is not “real time”; you must exit the menu
to output the specified starting phase.
∧000.000 DEG
8 Save the change and turn off the menu.
The function generator beeps and displays a message to show that the
change is now in effect. You are then exited from the menu.
ENTERED
Next, you will configure one of the function generators to source an
external trigger from its rear-panel Ext Trig terminal.
9 On one instrument, go to the
TRIG OUT command in the PHASE
MENU
.
3: TRIG OUT
10 Move down a level and enable the external trigger.
ENABLE
Menu On/Off
Shift
∨
Enter
∨
Menu On/Off
Shift
Chapter 1 Quick Start
To phase lock using the triggered burst mode
