HOW
TO USE THE
FREE
RUN MODE
3
1
4
o
500
FEEDTHRU TERMINATION {OptiOllllIl Not
shown
on
BUC-
ceedlng drawings. Trigger from CluJnnel 2 on the rising edge.
@
2
3
4
PRESET
FUNCTION
FREQ
AMPTD
OFFSET
SYM
{blue
shlftl
FUNCTION
Sets
the
3314A
to Its basic operstlng state. This operating
state
Is
very
useful as
the common starting polnt
for
all operations. Note
that
FREE RUN is
the
active mode
sfter
instrument preset.
Press this key to changa
the
function
from
Sine to Square
to
Triangle to Function
OFF and
beck to SIne. Note
that
DC OFFSET Is
not
affected
by Function OFF.
Use
the
Modify
knob and I or I keys to cluJngs
the
valua
of
theso parameters.
Note
that
AMPTD and OFFSET ara completely independent paramaters end
that
variable
symmetry
18
not allowed
for
frequencies
~
2MHz
.
Function
Invert Inverts
the
outpUt
signal. Note
that
DC OFFSET is
not
Inverted
and
that
the
inversion is
with
respect to
the
SYNC
output.
Free Run Summary
Functions: Sine, Square, Triangle , Function
Off
Frequency:
.001
Hz to
19.99MHz
In 8 ranges
Amplitude: .OOmVp-p to
10.00Vp-p
In 4 renges
Offset
: ± .
OOQ
VDC
to
± 6.QOVDC In 2 rllnges
Symmetry
:
5""
to 96'10
for
frequencies <
2MHz
See
waveforms
1 through
lOin
the Waveform
Ubrllry
.
9
