HP 3314A Operating Manual

CALIBRATION (cant)
The following operations result in an amplitude calibration of the new function:
-FUNCTION key or "FU''', "FU2" or "FU3"
-RECALL 0 through 5 if a new function is recalled
-ARB
entry (no measurement) or exit
You cannot force the 3314A to only measure amplitude calibration constants from
the front panel while calibration measurements are disabled. From the HP-IB,
"CEFUxCD" (where x = the number of the current function), will enable calibra-
tion measurements, execute an amplitude calibration and then disable calibration
measurements.
Frequency Calibration
Frequency calibrations occur whenever the frequency range changes. During
calibration measurements,
the sync output is active (output is a TIL level
squarewave
at the calibration frequency).
8
7
6
6
4
3
2
1
30 mil
30 mil
30 mil
30 ms
30 mil
100 ms
500 mil
500 ms
< 1 6mVp-p at the programmed frequency
<1 5mVp-p at the programmed frequency
< 1SmVp-p at 100kHz
< 1 5mVp-p lit 10kHz
< 1 6mVp-p at 1kHz
< 16mVp-p at 199 .9Hz
< 1 5mVp-p lit •
< 1 5mVp-p at •
• The 3314A makes 7 measurements at various fr0QU8ncles to compute the calibration constants for ranges
1 and 2.
The following operations result in a frequency calibration of the new frequency
range:
-During
frequency entry when a range change occurs
-At mode changes
-RECALL 0
through 5
-Fixad
to variable symmetry
-Variable symmetry exit
-Preset symmetry (BLUE shift SYM)
-Preset
frequency (BLUE shift FREQ)
-Sweep entry (no measurement) or exit
-ARB entry (no measurement) or exit
-VCO OFF to ON while in ranges 7 or 8
49
