HOW

TO USE THE PHASE LOCK MODES

IIT£RIAL

PHASE

lOCK

@ @

Trigger from Channel 2 ff An X N.

Trigger from Clulnnel 1 If An + N.

EXmtIAI.

PHASE

LOCI

SUfI

ActiN

PRESET Presets

the

3314A

to II common startlng point.

ThIs key toggles

the

mode

between

FIn X N lind FIn + N.

Whlle

the

light

Is flashing,

LCK the

14A

Is measuring

the

fr&qullncy of the reference slgnal, setting

the

3314A

output

frequency to lin approximation

thllt

will be within

the

capture renge of the

phase locked

loop

and then phalle loeka to the reference. The

3314A

hall acquired

lock

when

the

light

III on continuously. When EXT Trigger III selected, the

3314A

phese-Iocb

lin

external signal you apply to

the

Trigger

Input

Use the

Modify

knob to change

the

ratio of

output

frequency to reference frequency.

Note

that

the

3314A

has to reacquire lock every time N changes.

4 PHASE

Ulle

the

Modify

knob to change

the

phaSII

relationship

between

the reference and

output

signal. 10 of phase refers

t 0 of

the

lower frequency signal {either

reference or

oetput)

5 SWfTR This parameter

sets

the period of the INTVL • reference· signa l when INT Trigger is

INTVL

selected.
