HP 3314A Operating Manual

Fin X N
41. Squarewaves in Quadrature
PRESET
MODE . . . . .
.. . . . . . . . .•.. . ... . .. .. . . An X N
AMPLITUDE
5Vp-p
OFFSET • .• . • . • . •. .. • . . . ..• . . . • .. . . . 2.6Vdc
PHASE . . . . • • . •. • . • • . . . .. . . . . . . . .. . ... 90
0
N 1
TRIGGER INTERVAL . . . . . . . . . . • . . • . . . • . . . . 1ms
FUNCTION . . . . . . . . . . . . . . . . . . . . .
.. SquarewBve
PR M06 AP6VO OF2.6VO PH90DG NM1EN n1MS FU2
42. 3 Pulses
PRESET
MODE . •
•• . .•• ..• . . .. • • • • . . .. ... •.. An X N
AMPUTUDE . .... . . . . . . • • . . .•.. .. .. . . 10Vp-p
SYMMETRY •. .. •• • . . • . . . . . • . . . . . • . • . . . 10%
N 3
FUNCTION . . . . . . . . . . . . . . . . . . . . . . . SQlJareWaVB
PR M05 AP10VO SY10PC NM3EN FU2
MAIN OUTPUT
TRIGGER
OUTPUT
MAIN OUTPUT
TRIGGER
OUTPUT
43. Trianglewaves
PRESET MAIN OUTPUT
MODE • •. .• • • •. •. •.. ... .. ..•. ". •. . . . An X N
AMPLITUDE " . .
... . . . . . ... . . . . .. . . . .. 10Vp -p
N 2
TRIGGER SOURCE . . . • . • . • • . • . . . . . . • • • EXT TRIGGER
TRIGGER SLOPE \
(negative edge) OUTPUT
TRIGGER THRESHOLD . . . • . • . . . . . . . . . • • . • . .
1V
FUNCTION .. . . . . . • . . . . . . . . . . . . . . . . . . Triangle
PR M06 APl0VO NM2EN SR2 SL2 LV1 FU3
External
Trigger Is a 100kHz. TIL squarewave
44. Sinewaves
PRESET
MODE . • . • • •
•• •• • •• • . • • . •. . . • • . • . • . An X N
AMPLITUDE . .• . ..• . .• . . ... . .. . .. . ... 10Vp-p
N 2
swrm INTVL ..... ... .•.. _. . . . . . . . . 16.66mS
PR M05 AP10VO NM2EN TI16 .66MS
45. Squarewaves
PRESET
MODE ..... .... .. ..••..•..... •• . ..• An X N
AMPliTUDE . . . . . . . . .. . • . •. . . . .. . ...• 10Vp-p
N 10
FUNCTION . . ... .. . . • . .. ..• .. ..• • . Squarewave
PR
M06 AP10VO NM10EN FU2
31
MAIN OUTPUT
TRIGGER
OUTPUT
MAIN OUTPUT
TRIGGER
OUTPUT
