HP 3314A Operating Manual

ARB (cent)
The maximum frequency for an ARB waveform is 2.5kHz (2 vectors of O.2ms each).
As
you increase the number of vectors in a waveform, the frequency of the waveform
decreases.
1
FREQ
=
.t1 t .. (V LEN, +V LEN
2
+ .. ; + V LEN
n
)
where O.2ms :s .t1 t :s 19.99ms
In an extreme case, if you build a waveform with 150 vectors and set each vector to
the maximum vector length of 127 with .t1 t set to 19 .99ms , the minimum frequency
for the waveform is 2.6mHz (381 seconds).
19.99ms .. (127 .. 150) = 381 seconds (6.3 minutes).
Insert Vector. The Insert Vector funct ion adds one vector to the current ARB wave. When
a
vector is inserted:
-
the vector is inserted immediately after the current vector (the current vector is
pointed
to by the Vector Marker and intensified by the Z Axis output).
- the inserted vector has V HGT = 0t V LEN = 1.
-
the vectors following the inserted vector are renumbered.
-
the Vector Marker is incremented by 1 and points to the inserted vector.
If the Vector Marker is pointing to the last vector, a new Vector 1 is inserted.
Invert Function. Invert Function inverts the output signal with respect to the SYNC out-
put. The DC Offset is not affected.
Mode. The only modes allowed in ARB are Free Run and Gate.
- Free Run
outputs a continuous signal. All triggers are ignored.
- Gate
outputs a continuous signal while the trigger level satisfies the slope
threshold conditions. The
output gates off after the trigger level changer
waveform is completed.
47b
