Table 2-1 Right-side components and their descriptions (continued)
Component Description
● Blinking white: The AC adapter is disconnected and the battery has
reached a low battery level.
● Amber: The AC adapter is connected and the battery is charging.
● O: The battery is not charging.
(7) Power connector Connects an AC adapter.
Left side
Table 2-2 Left-side components and their descriptions
Component Description
(1) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a deterrent, but it may
not prevent the computer from being mishandled or stolen.
(2) USB SuperSpeed port Connects a USB device, such as a cell phone, camera, activity tracker, or
smartwatch, and provides high-speed data transfer.
(3) USB Type-C port Connects a USB device, such as a cell phone, camera, activity tracker, or
smartwatch, and provides data transfer.
NOTE: Cables, adapters, or both (purchased separately) may be
required.
(4) Memory card reader Reads optional memory cards that enable you to store, manage, share,
or access information.
To insert a card:
1. Hold the card label-side up, with connectors facing the computer.
2. Insert the card into the memory card reader, and then press in on
the card until it is rmly seated.
To remove a card:
▲ Press in on the card, and then remove it from the memory card
reader.
(5) Drive light (select products only) ● Blinking white: The hard drive is being accessed.
(6) Power light ● On: The computer is on.
6 Chapter 2 Getting to know your computer
