SATA solid-state drive specications
Table 9-4 Solid-state drive specications
128-GB* 256-GB*
Dimensions
Height 1 mm 1 mm
Length 50.8 mm 50.8 mm
Width 28.9 mm 28.9 mm
Weight < 10 g < 10 g
Interface type SATA-3 (6 Gbps) SATA-3 (6 Gbps)
Transfer rate
Sequential Read Up to 520 MB/s Up to 540 MB/s
Random Read Up to 60K IOPs Up to 85K IOPs
Sequential Write Up to 160 MB/s Up to 280 MB/s
Random Write Up to 34K IOPs Up to 67K IOPs
Ready time, maximum 1.0 s 1.0 s
Access times
Logical 0.1 ms 0.1
Total logical sectors 250,069,680 500,118,192
Operating temperature
Operating 0° to 70°C (32°F to 158°F) 0° to 70°C (32°F to 158°F)
Nonoperating –40° to 95°C (–40°F to 203°F) –55° to 90°C (–67°F to 194°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less.
NOTE: Certain restrictions and exclusions apply. Contact technical support for details.
SATA solid-state drive specications 77
