Memory module
Table 5-6 Memory module descriptions and part numbers
Description Spare part number
4 GB memory module (SODIMM) L10598-855
8 GB memory module (SODIMM) 937236-855
16 GB memory module (SODIMM) 937438-855
Before removing a memory module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the rubber feet (see Computer feet on page 27).
3. Remove the bottom cover (see Bottom cover on page 29).
4. Remove the battery (see Battery on page 31).
To remove a memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
2. Remove the memory module by pulling it away from the slot at an angle (2).
Reverse this procedure to install a memory module.
36 Chapter 5 Removal and replacement procedures for authorized service provider parts
