3-122

Performance Tests

Performance Test Record

3-12 Step 16: 34 Mb/s 17.18389227 MHz 17.1840774 MHz

Step 18: 34 Mb/s +20ppm 17.184266 MHz 17.184421 MHz

Step 20: 34 Mb/s -20ppm 17.183579 MHz 17.183734 MHz

Step 22: 34 Mb/s +100ppm 17.185641 MHz 17.185796 MHz

Step 24: 34 Mb/s -100ppm 17.182205 MHz 17.182359 MHz

3-13 Step 26: 140 Mb/s 69.6316865 MHz 69.6323185 MHz

Step 28: 140 Mb/s +15ppm 69.632731 MHz 69.633358 MHz

Step 30: 140 Mb/s -15ppm 69.630642 MHz 69.631269 MHz

Step 33: 1.544 Mb/s 1.543993 MHz 1.544007 MHz

Step 35: 1.544 Mb/s +32ppm 1.544042 MHz 1.544056 MHz

Step 37: 1.544 Mb/s -32ppm 1.543944 MHz 1.543958 MHz

3-14 Step 40: 44.736 Mb/s 44.735799 MHz 44.736201 MHz

Step 42: 44.736 Mb/s +20ppm 44.736693 MHz 44.737096 MHz

Step 44: 44.736 Mb/s -20ppm 44.734904 MHz 44.735307 MHz

PDH/DSn Transmitter

Output

3-16 139.264Mb/s (E4)

Step 7: All 1’s Pulse Pass/Fail

Step 8: Pulse amplitude 0.45V pk 0.55V pk

Step 12: All 0’s Pulse Pass/Fail

Step 13: Pulse amplitude 0.45V pk 0.55V pk

3-19 34.368Mb/s (E3)

Step 7: +ve Pulse Pass/Fail

Step 8: +ve Pulse amplitude 0.900V pk 1.100V pk

Step 12: -ve Pulse Pass/Fail

Step 13: -ve Pulse amplitude 0.900V pk 1.100V pk

Table 6 Performance Test Record continued

Page

No.

Test Description Result

Min Actual Max

HP 37718A User Manual
