3-123

Performance Tests

Performance Test Record

3-21 8.448Mb/s (E2)

Step 7 +ve Pulse Pass/Fail

Step 8: +ve Pulse amplitude 0.900V pk 1.100V pk

Step 12: -ve Pulse Pass/Fail

Step 13: -ve Pulse amplitude 0.900V pk 1.100V pk

3-23 2.048Mb/s (E1)

Step 7: +ve Pulse Pass/Fail

Step 8: +ve Pulse amplitude 2.133V pk 2.607V pk

Step 12: -ve Pulse Pass/Fail

Step 13: -ve Pulse amplitude 2.133V pk 2.607V pk

3-26 44.736Mb/s (DSX3)

Step 7: +ve Pulse Pass/Fail

Step 8: +ve Pulse amplitude Pass/Fail

Step 12: -ve Pulse Pass/Fail

Step 13: -ve Pulse amplitude Pass/Fail

Step 14: High amplitude Pass/Fail

Step 15: Low amplitude Pass/Fail

3-28 1.544Mb/s (DSX1)

Step 7: +ve Pulse Pass/Fail

Step 8: +ve Pulse amplitude 1.984V pk 2.976V pk

Step 12: -ve Pulse Pass/Fail

Step 13: -ve Pulse amplitude 1.984V pk 2.976V pk

Step 14: Low amplitude Pass/Fail

Table 6 Performance Test Record continued

Page

No.

Test Description Result

Min Actual Max

HP 37718A User Manual
