3-126

Performance Tests

Performance Test Record

Step 21: -ve Amp 2Mb/s 2.133 V pk 2.607 V pk

Step 1: DS-1 Bit & Code EC Pass/Fail

Step 1: DS-1 Bit Error Add Pass/Fail

Step 6: +ve Pulse Mask DS-1 Pass/Fail

Step 7: +ve Pulse Amp DS-1 1.896 V pk 2.844 V

Step 11 -ve Pulse Mask DS-1 Pass/Fail

Step 12: -ve Pulse Amp DS-1 1.896 V pk 2.844 V pk

3-54 PDH Frequency

Measurement and

Looped Clock

Step 8: 2Mb/s frequency 2.047991 MHz 2.048009 MHz

Step 9: Offset (0 ppm) -4.5 ppm +4.5 ppm

Step 10: Frequency+100 ppm 2.048194 MHz 2.048214 MHz

Step 11: Offset +100 ppm +95.5 ppm +104.5 ppm

Step 12: Frequency-100 ppm 2.047786 MHz 2.047806 MHz

Step 13: Offset -100 ppm -95.5 ppm -104.5 ppm

Step 13: Frequency Counter Pass/Fail

Step 14: 8Mb/s 0 ppm -4.5 ppm +4.5 ppm

Step 14: 8Mb/s -100 ppm -95.5 ppm -104.5 ppm

Step 14: 8Mb/s +100 ppm +95.5 ppm +104.5 ppm

Step 14: 34 Mb/s 0 ppm -4.5 ppm +4.5 ppm

Step 14: 34 Mb/s -100 ppm -95.5 ppm -104.5 ppm

Step 14: 34 Mb/s +100 ppm +95.5 ppm +104.5 ppm

Step 14: 40 Mb/s 0 ppm -4.5 ppm +4.5 ppm

Step 14: 140 Mb/s -100 ppm -95.5 ppm -104.5 ppm

Step 14: 140 Mb/s +100 ppm +95.5 ppm +104.5 ppm

Table 6 Performance Test Record continued

Page

No.

Test Description Result

Min Actual Max

HP 37718A User Manual
