3-128

Performance Tests

Performance Test Record

Step 11: -100ppm 51.8348149MHz 51.8348171MHz

Step 11: -66ppm 51.8365464MHz 51.8365485MHz

Step 11: +33ppm 51.8417252MHz 51.8417273MHz

Step 11: +100ppm 51.8451829MHz 51.8451851MHz

Step 11: +999ppm 51.8917871MHz 51.8917892MHz

3-66

STM-0/STS-1 Transmitter

Output Waveshape

Step 6: +ve Pulse Pass/Fail

Step 7: +ve Pulse Amp Pass/Fail

Step 11: -ve Pulse Pass/Fail

Step 12: -ve Pulse Amp Pass/Fail

Step 13: High amplitude Pass/Fail

Step 14: Low Amplitude Pass/Fail

3-70

STM-1/STS-3 Transmitter

Output Waveshape

Step 8: All 1’s Pulse Pass/Fail

Step 9: Pulse Amp 450 mV pk 550 mV pk

Step 13 All 0’s Pulse Pass/Fail

Step 14: Pulse Amp 450 mV pk 550 mV pk

3-75

SDH/SONET Receiver

Equalization

Step 5: STM-0/STS-1 Pass/Fail

Step 10: STM-1/STS-3 Pass/Fail

3-78

SDH/SONET Receiver

Monitor Levels

STM-0/STS-1

Step 5: 20dB Pass/Fail

Table 6 Performance Test Record continued

Page

No.

Test Description Result

Min Actual Max

HP 37718A User Manual
