HP 37718A User Manual

3-135
Performance Tests
Jitter Performance Test Record (options 204, 205 & 206)
step 41 No SDH
errors
Pass/Fail
3-115
STM 4 Optical
Step 49 Optical Power dBm N/A N/A
step 8 No SDH errors Pass/Fail
step 8 Rx result N/A 0.070 UI p-p
step 9 Rx result N/A 0.070 UI p-p
step 13-15 Tx result 0.15 UI p-p 0.25 UI p-p
step 13-15 Rx result 0.118 UI p-p 0.284 UI p-p
step 14 No SDH
errors
Pass/Fail
step 18-20 Tx result 0.15 UI p-p 0.25 UI p-p
step 18-20 Rx result 0.111 UI p-p 0.291 UI p-p
step 19 No SDH
errors
Pass/Fail
step 22-25 Tx result 0.82 UI p-p 1.00 UI p-p
step 22-25 Rx result 0.776 UI p-p 1.044 UI p-p
step 24 No SDH
errors
Pass/Fail
step 27-31 Tx result 3.30 UI p-p 3.74 UI p-p
step 27-31 Rx result 3.174 UI p-p 3.866 UI p-p
step 30 No SDH
errors
Pass/Fail
step 33-37 Tx result 10.90 Ui p-p 12.14 UI p-p
step 33-37 Rx result 10.401 UI p-p 12.426 UI p-p
step 35 No SDH
errors
Pass/Fail
Table 7 Performance Test Record continued
Page
No.
Test Description Result
Min Actual Max
