Performance Tests
Jitter Performance Test Record (options 204, 205 & 206)
step 39-43 Tx result 124.37 UI p-p 139.63 UI p-p
Step 49 step 39-43 Rx result 113.40 UI p-p 150.60 UI p-p
step 41 No SDH
errors
Pass/Fail
3-116
STM 16 Optical
Step 50 Optical Power dBm N/A N/A
step 8 No SDH errors Pass/Fail
step 8 Rx result N/A 0.070 UI p-p
step 9 Rx result N/A 0.070 UI p-p
step 13-15 Tx result 0.14 UI p-p 0.26 UI p-p
step 13-15 Rx result 0.114 UI p-p 0.286 UI p-p
step 14 No SDH
errors
Pass/Fail
step 18-20 Tx result 0.13 UI p-p 0.27 UI p-p
step 18-20 Rx result 0.100 UI p-p 0.300 UI p-p
step 19 No SDH
errors
Pass/Fail
step 22-25 Tx result 0.81 UI p-p 1.01 UI p-p
step 22-25 Rx result 0.795 UI p-p 1.026 UI p-p
step 24 No SDH
errors
Pass/Fail
step 27-31 Tx result 3.29 UI p-p 3.75 UI p-p
step 27-31 Rx result 3.124 UI p-p 3.916 UI p-p
step 30 No SDH
errors
Pass/Fail
step 33-37 Tx result 8.99 Ui p-p 10.05 UI p-p
step 33-37 Rx result 8.53 UI p-p 10.34 UI p-p
Table 7 Performance Test Record continued
Page
No.
Test Description Result
Min Actual Max
