HP 37718A User Manual

3-42
Performance Tests
PDH/DSn Receiver Monitor Levels
16 Press and select EQUALIZATION [OFF].
17 Press ; then to start the
measurement.
18 EnsurethatNO TROUBLEisdisplayedon the displayafter
30 seconds. Press to stop the measurement.
19 Remove the 6dB fixed attenuator and connect the 10dB Fixed
Attenuator in the signal path to give a total path attenuation of 30dB.
20 Press and set MONITOR LEVEL [30dB].
21 Press then to start the
measurement.
22 EnsurethatNO TROUBLEisdisplayedon the displayafter
30 seconds. Press to stop the measurement.
23 Press and select EQUALIZATION [ON].
24 Connect Cable Simulator E1-M between the PDH OUT Port and the
attenuator.
25 Press . Press to start the
measurement.
26 EnsurethatNO TROUBLE isdisplayedon the displayafter
30 seconds. Press to stop the measurement.
8.448 Mb/s (E2)
27 Repeat steps 1 to 26 (20dB,26dB and 30dB tests) with the HP 37718A/
19A and displays set to SIGNAL [8 Mb/s] and
Cable Simulator E2-M fitted in place of Cable Simulator E1-M.
34.368 Mb/s (E3)
28 Repeat steps 1 to 18 (20dB and 26dB tests) with the HP 37718A/19A
and displayssetto SIGNAL[34 Mb/s]and Cable
Simulator E3-M fitted in place of Cable Simulator E1-M.
139.264 Mb/s (E4)
29 Repeat steps 1 to 18 (20dB and 26dB tests) with the HP 37718A/19A
and displays set to SIGNAL [140 Mb/s] and
Cable Simulator E4-M fitted in place of Cable Simulator E1-M.
RECEIVE
RESULTS
TROUBLE SCAN
RUN/STOP
RESULTS
RUN/STOP
RECEIVE
RESULTS
TROUBLE SCAN
RUN/STOP
RESULTS
RUN/STOP
RECEIVE
RESULTS
TROUBLE SCAN
RUN/STOP
RESULTS
RUN/STOP
TRANSMIT
RECEIVE
TRANSMIT
RECEIVE
TRANSMIT
RECEIVE
