5: Hex-head bolt, Length ( 32mm /
1.26in ), Wrench size ( 6.85mm /
0.27in ), Thread size ( 3.91mm / 0.15in )
6: Hook
5. Attach the AP to the wall-mounting bracket. For more information, see
"Mounting the AP on a wall."
Removing the AP
To remove the AP from the bracket, insert a straight-edge screwdriver on
either side of the AP (in line with either the 2.4 GHz-2 or 5 GHz-2 antenna
ports) between the bracket and the clip. Rotate the screwdriver slightly so that
the clip flexes away from the bracket, and then slide the AP toward the
narrow end of the mounting bracket until the AP is released. Be sure to firmly
grip the AP so that it does not fall.
Technical support
For worldwide technical support information, see the HP support website at
www.hp.com/networking/support
.
Other regulatory information
For important safety, environmental, and regulatory information, see Safety
and Compliance Information for Server, Storage, Power, Networking, and
Rack Products, available at
www.hp.com/support/Safety-Compliance-EnterpriseProducts
.
FCC Notice
This device must not be co-located with any other transmitters except in
accordance with FCC multi-transmitter product procedures.
Referring to the multi-transmitter policy, multiple-transmitter(s) and module(s)
can be operated simultaneously without C2P.
12

HP 525 Specifications

General

Device Type	Wireless Access Point
Frequency Band	2.4 GHz and 5 GHz
Ethernet Ports	1
Wireless Protocol	802.11a/b/g/n
Ports	1 x 10/100/1000 Ethernet port
PoE	802.3af
Antennas	2 internal antennas
Security Features	WPA, WPA2
Power Source	PoE or External Power Adapter
Operating Temperature	0°C to 40°C (32°F to 104°F)
Dimensions	5.7 x 5.7 x 1.3 inches (145 x 145 x 33 mm)
