Figure 2 Screw hole locations and sizes (in mm)
1: Hook
2: Mounting hole
3: Clip
4: Mounting clip
2. Drill three holes for the wall anchors, typically 5 mm (3/16 inch) in
diameter.
3. Insert the anchors and tap them flush with the wall surface.
4. Use the mounting screws to attach the mounting bracket to the wall.
Ø5.0
40.0
103.0
86.0
136.0
1
2
4
3
6

Other manuals for HP 525

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 525 and is the answer not in the manual?

HP 525 Specifications

General IconGeneral
Device TypeWireless Access Point
Frequency Band2.4 GHz and 5 GHz
Ethernet Ports1
Wireless Protocol802.11a/b/g/n
Ports1 x 10/100/1000 Ethernet port
PoE802.3af
Antennas2 internal antennas
Security FeaturesWPA, WPA2
Power SourcePoE or External Power Adapter
Operating Temperature0°C to 40°C (32°F to 104°F)
Dimensions5.7 x 5.7 x 1.3 inches (145 x 145 x 33 mm)
