Figure 3 Installing the wall-mounting bracket
3: Clip 4: Screw, Length ( 17.4mm / 0.69in ),
Wrench size ( 6.5mm / 0.26in ), Thread size
5. Connect the Ethernet cable to the AP.
6. Align the AP mounting hook holes with the hooks on the AP bracket.
7. Push the AP onto the mounting bracket, and then slide it down until it is
fully engaged.
7
