SVC 5-8
FAN SHROUD
SENSOR
SCREWS
HEATER
STANDOFFS
Fan Shroud
FAN SHROUD (AS VIEWED FROM INSIDE OVEN)
10. Note the position of the sensor so it may be replaced at the same location.
11. Loosen the retainer clamp sufficiently to free the sensor.
HEATER STANDOFFS SENSOR
HEATER ELEMENT
HEATER ELEMENT (AS VIEWED FROM REAR OF SHROUD)
12. Remove the two screws securing the heater to its standoffs.
