SFP+ port
HP 5920AF-24XG, 5920AF-24XG TAA, 5900AF-48XG-4QSFP+, 5900AF-48XG-4QSFP+ TAA and
5900AF-48G-4XG-2QSFP+ switches have fixed SFP+ ports. You can plug the SFP transceiver modules
in Table 7, th
e SFP+ transceiver modules in Table 8, and the SFP+ cables in Table 9 into the SFP+ ports
as needed. You can use the SFP+ ports as IRF physical ports to connect the switches in an IRF
deployment.
Table 7 1000 Mbps SFP transceiver modules available for the SFP+ ports
Product
Code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
JD089B
HP X120 1G SFP RJ45 T
transceiver
N/A
Category-5
twisted pair
N/A
100 m (328.08
ft)
JD118B
HP X120 1G SFP LC SX
transceiver
850 50/125
500
550 m (1804.46
ft)
400
500 m (1640.42
ft)
JD119B
HP X120 1G SFP LC LX
transceiver
1310 9/125 N/A
10 km (6.21
miles)
JD061A
HP X125 1G SFP LC
LH40 1310nm
transceiver
1310 9/125 N/A
40 km (24.86
miles)
JD062A
HP X120 1G SFP LC
LH40 1550nm
transceiver
1550 9/125 N/A
40 km (24.86
miles)
JD063B
HP X125 1G SFP LC
LH70 transceiver
1550 9/125 N/A
70 km (43.50
miles)
Table 8 10 Gbps SFP+ transceiver modules available for the SFP+ ports
Product
Code
Module
description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max transmission distance
JD092B
HP X130 10G
SFP+ LC SR
transceiver
850 50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
JD093B
HP X130 10G
SFP+ LC LRM
transceiver
1310 62.5/125
200
160
220 m (721.78 ft)
JD094B
HP X130 10G
SFP+ LC LR
transceiver
1310 9/125 N/A 10 km (6.21 miles)
