HP 8719ET - Page 76

2-16
HP 8719/20/22ET Specifications and Characteristics
Instrument Specifications
Table 2-12 Test Port Output
HP 8722ET Test Port Output
Description Specification Supplemental Information
Output Power
Linearity
a
a. Change in source output power for a given change in source power setting at any
given frequency.
Test Reference Power: −5 dBm
−5 dB from reference
50 MHz to 20 GHz ± 0.35 dB
20 GHz to 40 GHz ± 0.6 dB
+5 dB from reference
± 0.35 dB
± 0.6 dB
50 MHz to 20 GHz
−10 dB from reference
Impedance
Standard 50 Ω, nominal
Attenuator Accuracy
b
(Option 004 Only)
b. The accuracy, relative to the 0 dB setting, of each setting of an attenuator, at a
given frequency.
0 dB reference; at 50 MHz
5 dB ±0.5 dB, char.
10 dB ±0.5 dB, char.
15 dB ±0.6 dB, char.
20 dB ±0.6 dB, char.
25 dB ±0.7 dB, char.
30 dB ±0.7 dB, char.
35 dB ±1.0 dB, char.
40 dB ±1.0 dB, char.
45 dB ±1.2 dB, char.
50 dB ±1.2 dB, char.
55 dB ±1.6 dB, char.
