2-17
HP 8719/20/22ET Specifications and Characteristics
Instrument Specifications
Test Port Input
Table 2-13 Test Port Input
HP 8719ET/20ET/22ET Test Port Input
Description Specification Supplemental Information
Frequency Range
HP 8719ET 0.05 to 13.51 GHz
HP 8720ET 0.05 to 20.05 GHz
HP 8722ET 0.05 to 40.05 GHz
Frequency Response (B, R)
Channel R
0.05 to 20.05 GHz ± 1.5 dB, char.
20.05 to 32 GHz ± 2.5 dB, char.
32 to 40 GHz +2.5 dB to −6 dB, char.
Channel B
0.05 to 20.05GHz ± 2.5 dB, char.
20 to 32 GHz ± 3.0 dB, char.
32 to 40 GHz +3.0 dB to −6 dB, char.
Impedance
Standard 50 Ω, nominal.
Return Loss
Standard See uncorrected load match chart.
Maximum Input Level
a
a. Maximum level at which no test port overload messages are seen.
Standard +5 dBm, Transmission Port
+10 dBm, Reflection Port
Damage Level
Standard +27 dBm or > 0 Vdc, typ.
Compression See dynamic accuracy chart.
